Cold Storage Room Custom Walk-In Cooler / Freezer Combo With Remote Refrigeration
PU cold storage room panel is a kind of board used for enclosing structures, which has good heat insulation. It can reduce the heat transmission caused by difference in the internal and external temperature, and get to maximum efficiency of freezing and refrigeration systems. It is a new type of heat insulation material for lower construction cost. Panels are in multiple varieties and specifications to meet the need of various sites and projects.
The standard panel thickness: 100mm, 120mm, 150mm and 200mm
The temperature range optional: 0~10℃,-10~-18℃,-18~-22℃,-35℃
100mm width can keep temp at 0℃(suit for fresh keeping)
150mm width can keep temp at -25℃(suit for cold storage)
200mm width can keep temp at -38℃(suit for freezing)
| Product name | Polyurethane(PU) Sandwich Board |
| Thickness | core material | 75mm, 100mm, 120mm,150mm,200mm |
| Effective Width | standard | 950mm, 970mm,1000mm,1150mm |
| Length | can be customized,less than 12m |
| Density | 40-42kg/m3 |
| Color | white |
| Fire resistance level | B2 |
| Parts | Eccentric hook used for connection of panel |
| Film covering for protecting the surface layer |
| Characteristics | heat insulation energy-saving | 100mm width can keep temp at 0℃(suit for fresh keeping) |
| 150mm width can keep temp at -25℃(suit for cold storage) |
| 200mm width can keep temp at -38℃(suit for freezing) |
| Water resistance and sound proof |
| Weather proofing |
| Fire retardant level:B2 |
| High strength and bending resistance |
| Easy quick installation and dismantling,labour cost saving |
| Light weight compared to traditional stone or plaster panel |
| Safe and green,good appearance,without formaldehyde |
| Usage | Can be used for wall,roof,floor and partition of cold storage, mobile house, suburban housing, warehouses, supermarkets, activities room,clean workshop. |
1.Feature of cold storage
- designed for beef,meat quickly to frozen:
- Temperature range:0~10℃,0~-18℃,or -18~20℃
- Available for Famous Brand,Copleand and Danfoss condensing unit
- Available thickness of 100% PU sandwich panel:100mm,120mm and 150mm with gasket and flame retardant
- Available for hinged door and sliding door.
- We can offer complete cold storage equipments including the condensing untis,air coolers,control box,expansion valve,copper pipe,insulation pipe,etc.
- Room size:as customer required.Like Width*Depth*Height 3*3*2.5m,8*5*4m etc.
2.Feature of modular cold room
- temperature range: -40~+15c are all available.
- size: Customization.
- functions: Fresh-keeping. Freezing, quick-freezing. Fire-proof. Air-conditioning are all available.
- fully automatic control system. Components:
- condensing unit: Famous Brand, Copeland, Bitzer
- evaporator: Eltess air-cooler.
- insulation panel: Polyurethane
Customize idea,Different size, different temperature for keeping different goods available to make.
4.Application of cold storage
Food(meat, vegetable, fruit, dairy, drink), medicine, chemical, electronics, etc.
-- materials: Polyurethane and metal sheet. Metal sheet: It is can be with painted steel sheet and stainless steel sheet for choice.
-- with electric heating wire around doorframe to avoid icing.
-- safe doorknob inside.
-- positive plastic seal fixed to door to avoid cooling air losses.
-- we can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements.
